Secure Thermal Design Margin in Compact Equipment
with OMRON G6K-T1
As electronic systems become more compact and powerful, rising PCB temperatures are creating new design challenges. The OMRON G6K-T1 combines a miniature footprint with operation up to 125°C and switching currents up to 2A, enabling reliable switching in high-density PCB designs.
It is especially suitable for Test/Measurement equipment, HVAC Controllers, FA Motor etc where Higher functionality and miniaturization are required.
Benefits
- Operates up to 125°C
- More thermal headroom
- Lower cooling costs
- Compact system design
- Space-saving footprint
- Reliable mechanical switching
Features
- 125°C operating temperature
- 2A switching current
- Compact 5.2 (H) × 6.5 (W) × 10 (L) mm size
- DPDT contacts
- 140 mW power consumption
- High-density PCB mounting
Designed for Compact Electronics
As electronic equipment becomes more compact and feature-rich, designers are challenged to fit more functionality into less space. The OMRON G6K-T1 helps address this trend with a miniature relay design that supports high-density PCB layouts without compromising performance.
More Freedom in Thermal Design
Rising PCB temperatures can limit design flexibility and increase the need for thermal countermeasures. With support for operating temperatures up to 125°C, the G6K-T1 helps engineers maintain sufficient thermal design margins, enabling reliable operation even in demanding environments.
Ready for Next-Generation Applications
From Test & Measurement equipment to HVAC controllers and Factory Automation systems, the G6K-T1 supports applications where higher functionality and miniaturization are essential. By combining compact dimensions with enhanced temperature performance, it helps engineers create smaller, more efficient, and more reliable products.
